BIANCHI INFINITO XE DISC ULTEGRA 8000 BIKE SPECIFICATIONS
- Cassette Shimano Ultegra 8000 11-speed 11-32
- Chain Shimano HG701 11-speed
- Pedals Not Included
- Tires Vittoria Zaffiro Pro V 700x28c
- Wheel – Front Fulcrum Racing 918
- Wheel – Rear Fulcrum Racing 918
- Rotors Shimano RT800 160mm
- Frame Material Carbon, 12x142mm Thru-Axle
- Fork Full Carbon, 12x100mm Thru-Axle
- Headset FSA NO.42/47CF/ACB/5D
- Seatpost Velomann Alloy 2014, 31.8mm
- Front Derailleur Shimano Ultegra 8000
- Rear Derailleur Shimano Ultegra 8000
- Crankset Shimano Ultegra 8000, 50/34
- Bottom Bracket Shimano BB71-41B
- Brake Calipers Shimano Ultegra 8070
- Shifters / Levers Shimano Ultegra 8020
- Stem Velomann 3D Forged
- Handlebar Velomann Compact Flat Top
- Saddle Velomann
BIANCHI INFINITO XE DISC ULTEGRA 8000 BIKE GEOMETRY / SIZE CHART
| Size | Seat Tube (c-c) | Seat Tube (c-t) | Top Tube Length | Head Tube Length | Chain Stay Length | Seat Tube Angle | Head Tube Angle | Stand Over Height | Wheel Size | Stack | Reach |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 47 | – | 426 | 515 | 105 | 410 | 74.5 | 70.5 | 700c | 490 | 376 | |
| 50 | – | 452 | 525 | 110 | 410 | 74.5 | 71.5 | 700c | 499 | 384 | |
| 53 | – | 481 | 535 | 125 | 410 | 74.0 | 72.0 | 700c | 524 | 385 | |
| 55 | – | 500 | 550 | 140 | 410 | 73.5 | 72.5 | 700c | 540 | 389 | |
| 57 | – | 520 | 560 | 155 | 410 | 73.5 | 73.0 | 700c | 556 | 395 | |
| 59 | – | 540 | 575 | 175 | 412 | 73.0 | 73.0 | 700c | 575 | 398 | |
| 61 | – | 560 | 585 | 195 | 413 | 72.5 | 73.0 | 700c | 595 | 398 |
